Wi-Fi 6 (AX3000) | Dual-Band (2.4GHz & 5GHz) | Up to 3000Mbps | Ultra-thin design | Seamless wall-mount | MU-MIMO | Fast roaming
Ceiling-mounted access point with Wi-Fi 6 (802.11ax) for faster and broader coverage
Dual-band support (2.4GHz + 5GHz) for stable and high-speed wireless performance
Ideal for enterprise, hotels, and schools requiring reliable network connectivity
Sleek design with easy ceiling installation for optimal signal distribution
Product Information | |
|---|---|
Model | W39AP |
Category | In-wall |
Dimension | 86*86*32mm |
Hardware Specifications | |
Interface | One 10/100/1000 Mbps Ethernet Port |
Button | 1*Reset |
LED indicator | 1*SYS |
Maximum Power Consumption | 8.5W |
Power Supply | PoE 802.3af |
Max. Number of Clients | 256 |
Recommended Clients | 60 |
Antenna | 4*4dBi |
2.4GHz maximum power | 11b mode, transmit power 17±1.5dBm |
5GHz maximum power | 11a mode, transmit power 16±1.5dBm |
Reception Sensitivity | 2.4GHz 802.11b -98dBm |
Frequency Range | 2.4GHz&5GHz |
Standard&Protocol | IEEE 802.11b/g/n/ac/ax(wave2) |
Maximum wireless speed | 2.4GHz: 574Mbps |
Bandwidth | 20MHz/40MHz/80MHz/160MHz |
