Pro-7-Lite
Wi-Fi 7 Ceiling AP
Dual-band mesh Wi-Fi system (2.4GHz + 5GHz)
Speeds up to AC1200 for strong and stable coverage
Seamless roaming for uninterrupted connectivity
Gigabit ports for high-speed wired connections
Ideal for large homes and multi-floor offices
Easy setup through dedicated app
Advanced encryption for network security and privacy
Product Information | |
|---|---|
Model | Pro-7-LR |
Category | Ceiling |
Dimension | Φ250.6*55 mm |
Hardware Specifications | |
Interface | 1*100/1000/2500Mbps Ethernet Port (PoE) |
Button | 1*Reset |
LED indicator | 1*SYS |
Maximum Power Consumption | 17.4W |
Power Supply | PoE 802.3at |
Max. Number of Clients | 256 |
Recommended Clients | 100 |
Antenna | 2*4dBi + 3*4dBi |
2.4GHz maximum power | • CE: <20 dBm (2.4 GHz, EIRP) |
5GHz maximum power | • CE: <23 dBm(5 GHz, EIRP) |
Reception Sensitivity | 2.4GHz 802.11b -98dBm |
Frequency Range | 2.4GHz&5GHz |
Standard&Protocol | IEEE 802.11b/g/n/ac/ax/be |
Maximum wireless speed | 2.4GHz: 688Mbps |
Bandwidth | 20MHz/40MHz/80MHz/160MHz |
