DMA30W
33.260KWD
Tags:
Remote Control Panel
- Mechanicalknobsandpush-button design, with a rocker-type power switch.
- Two-channel amplifier; each channel can be individually configured via DIP switches to support 100V constant-voltage output, 70V constant-voltage output, 8Ω fixed-resistance output, or 4Ω fixed-resistance output. Rated power can be delivered in any mode.
- Six balanced input channels, each with independent volume control; each channel has a separate DIP switch for 48V phantom power.
- OnesetofRCAAUX2inputs, splitinto CH1 and CH2, with independent volume control.
- One3.5mmstereoinput,with independent volume control for CH1 and CH2.
- TwoRCAAMPIN1-2inputsforamplifier input, by default connected to PRE OUT1-2.
- TwoRCAPRE OUT1-2 outputs for preamplifier output, controlled by CH1 and CH2 volume; outputs 1V only in 100V constant-voltage mode.
- 3.5mmstereo input and MIC1 can be configured as priority inputs; in any mode, these two inputs are mixed together.
- Two RCA AUX2 OUT1-2 outputs for audio sources, not controlled by CH1/CH2 volume or maximum output level.
- RJ45 interface supports DMA30W remote touch control panels, up to six units; allows control of CH1/CH2 volume, zone on/off, and EFFECT on/off.
- Supports EFFECT (reverb) depth adjustment and reverb time with three preset modes and one custom
