8 Inch 8 Ohms Frameless In-Ceiling Speakers
5-inch wall mount speaker
Equipped with power tap for adjustable wattage
Clear sound ideal for background music and paging
Compact design suitable for indoor commercial use
Easy wall-mount installation
Model | DSP8040 | DSP8050 | |
Tweeter | 1” (25mm) silk soft dome | 1” (25mm) silk soft dome | |
Woofer | 6” (165mm) graphite cone, rubber surround | 8” (203mm) graphite cone, rubber surround | |
Frequency Range +/-3 | 60Hz-20kHz | 43Hz-20kHz | |
Power Handing RMS | 80W program, 40W (IEEE 219) | 100W program, 50W (IEEE 219) | |
Sensitivity | 87dB | 87dB | |
Power Adjustment | 8Ω | 40W | 50W |
100V | 40W/20W/10W/5W | 50W/25W/12.5W/6.25W | |
Termination | Standard pressed connector | Standard pressed connector | |
Attachment | Cutout template grille | Cutout template grille | |
Dimensions (W*H) | 248.5mm×108mm | 285.5mm×121mm | |
Cut-Out Diameter | 8.23” (209mm) | 9.8” (249mm) | |
Material | ABS | ABS | |
