Pro-6-M

Model

Pro-6-Mini

Category

Ceiling

Dimension

φ176*43.5mm

Interface

One 10/100/1000 Mbps Ethernet Port (PoE)

Button

1*Reset

LED indicator

1*SYS

Maximum Power Consumption

10.5W

Power Supply

PoE 802.3af

Max. Number of Clients

256

Recommended Clients

50

Antenna

4*4dBi

2.4GHz maximum power

11b mode, transmit power 22±1.5dBm
11g mode, transmit power 22±1.5dBm
11n mode, MCS7 transmit power 20±1.5dBm

5GHz maximum power

11a mode, transmit power 22±1.5dBm
11n mode, MCS7 transmit power 19±1.5dBm
11ac mode, MCS9 transmit power 15±1.5dBm
11ax mode, MCS11 transmit power 15±1.5dBm

Reception Sensitivity

2.4GHz 802.11b  -98dBm
2.4GHz 802.11n (MCS7)  -77dBm
5GHz 802.11a  -95dBm
5GHz 802.11n (40M-MCS7)  -76dBm
5GHz 802.11ax (80M-MCS11)  -64dBm

Frequency Range

2.4GHz&5GHz

Standard&Protocol

IEEE 802.11b/g/n/ac/ax

Maximum wireless speed

2.4GHz: 300Mbps
5GHz: 1201Mbps

Bandwidth

20MHz/40MHz/80MHz
